How to Debounce Button Inputs in Real Time Operating Systems

By April 11, 2023No Comments

Luis Ubieda is the Lead Firmware Engineer at Croxel. He has a background in Electrical Engineering and is passionate about Electronics, Embedded Systems, and IoT Technology.

This article originally ran on the Golioth website. For more content like this, click here

Embedded systems are riddled with complexity, mainly because they are at the intersection of expertise. Problem are often a mixture of software, electrical and mechanical issues. This is the case even for seemingly simple tasks, such as reliably detecting a button-press.

“Wait — a button-press??”

Let’s think for a second, how a button press is detected:

  1. Initial State: a button-press typically consists of a “normally-open switch”, which through a pull-up/down resistor, is normally “high” or normally ‘low’: this is the initial state.
  2. Press Event: then, when the button is pressed, the switch is closed and the signal transitions towards the opposite state (e.g, low for normally “high” state), and it’s sustained for as long as the button is held by the user.
  3. Release Event: Finally, when the button is released, it goes back to its initial state.

diagram showing the busy electrical signal produced at the beginning of a button press

Image: Signal during a button-press/release sequence where the transitions are outlined; and the scoped signal has noise. Source: GeeksforGeeks.

In an ideal world, we could just look at the signal edges to keep track of the transitions and assume a falling edge is a “press-event” and rising edge the “release event”. In our world, these transitions are affected by electrical transients caused by the mechanical properties of the button actuator. The suppression of this noise it’s commonly called “debouncing”.

“Ok, I get it. How can we `debounce` button-presses?”

There are two main ways we can approach this: the hardware-way and the software-way. Today I’ll touch on both, and detail the technique I prefer to use when debouncing button input with the Zephyr RTOS.

The Hardware Way

The hardware-way focuses on the root cause: the electrical noise. It guarantees the digital signal won’t have such noise during transitions; and it does it through the use of low-pass filters (most probably RC-filters). There are some pretty cool articles that detail this approach (see references at the end of the article).

The Software Way

On the other hand, the software-way is about “ignoring” these false positives on the signal transitions to determine which ones are the real events we’re looking for, and which ones aren’t. Even though there are many ways implement software debouncing, there are two main approaches, depending on whether the variable of interest is the signal state or the transitions: periodic sampling and tracking edge interrupts.

A. Periodic Button State Sampling

Button sampling works by periodically acquiring the signal state, which is buffered on a continuously rolling sample-set. Through detection of consecutive states, the signal change event is detected (either pressed or released). The rule is simple: if there are X-number of consecutive samples with a changed state, we assume the transition really happened. This periodic sampling is often in the order of 10 to 25-ms and is commonly paced by a hardware timer to guarantee fixed intervals and to free some CPU usage.

diagram showing a series of 1 and 0 signals sampled to detect a button press

B. Tracking Edge-Interrupts with Minimum Cooldown

This works by coordinating the detection of edge changes with the spacing between these: there must be a minimum duration before legitimate signal transition. This cooldown phase is commonly implemented through a timer, which kicks-off on the edge-interrupts: the timer gets restarted on each transition and only when it expires (after 10-ms to 25-ms of no edge-changes), the firmware handles the transition as an event.

diagram showing the ignored edges of a button press signal

Software Approach B: Tracking Edge-Interrupts with Minimum Cooldown

In multi-threaded systems, we can leverage the use of RTOS primitives to make the code more modular while simplifying the logic to achieve the same purpose: featuring a thread and semaphores to control the state transitions and decide when to notify the user of the module when an event occurred.

Example Code – Zephyr RTOS

The following code presents an example of achieving the software approach B on Zephyr, with the following observations:

  • We’re using Zephyr GPIO interrupt APIs to keep track of the edge-changes.
  • We’re using the system workqueue as the cooldown mechanism for false positives.
  • Our button-detection module, abstracts both of these details, and only notifies the user of the relevant events: pressed or released.
  • Note: the user callback context is the workqueue handler, therefore: actions on this context shall be kept brief to allow proper functioning of other parts of the system.

Check out the working sample code on https://github.com/ubieda/zephyr_button_debouncing

Conclusion

The most important part of debouncing inputs is to understand how far you should go and which approach best suits you. Cost sensitivity tends to favor software debouncing, whereas less CPU usage favors offloading it to the hardware approach. Like any engineering problem, there are 1000 ways to solve it: always favor the simplest (yet effective) solution that works for you.

References

Zephyr Project
